Aeris XR1 Nx Dive Computer Operating Manual
Download PDF user manual for Aeris XR1 Nx Dive Computer (EN) 72 pages Doc. No. 12-7215-r01 (2/20/07) zip
Description
This PDF operating manual is for the Aeris XR1 Nx dive computer.
About the Item
Aeris XR1 Nx Dive Computer
It is extremely important that you read this Operating Manual in sequence and understand it completely before attempting to use the XR1 Nx.
It is equally important that you read the AERIS Dive Computer Safety and Reference Manual (Doc. No. 12-7203) provided with your XR1 Nx. It contains information that you must become familiar with prior to diving with your XR1 Nx.
Remember that technology is no substitute for common sense, and a dive computer only provides the person using it with data, not the knowledge to use it.
The documents listed below are for reference only. For specific operational details, consult the original paper documents included with your product.
(PDF) OPERATING MANUAL (EN)
SUMMARY OF CONTENTS
– Notices
– Full LCD
FEATURES AND DISPLAYS
– Introduction
– Control Button
– Bar Graphs. Nitrogen Loading Bar Graph (NiBG). Oxygen Bar Graph (O2BG). Variable Ascent Rate Indicator (VARI).
– Alpha/Numeric Displays. Depth Displays. Time Displays. Temperature Display.
– Power Supply. Battery Indication. Low Battery Condition.
– FO2 Mode. FO2 50% default.
ACTIVATION AND SETUP
– Activation. Wet Contact Activation.
– Surface Sequence
– Surface Mode
– Dive Planner (Plan Mode)
– Set Mode. Set Mode Access and Timing.
– How to set FO2
– How to set Wet Activation
– How to set units of measure
– How to set hour format
– How to set time
– How to set PO2 Alarm
– How to set FO2 50% default
– Summary of Pre Dive Setup
PLAN AND DIVE MODES
– Pre Dive Planning Sequence
– NIBG (Nitrogen Bar Graph)
– O2BG (Oxygen Accumulation Bar Graph)
– VARI (Variable Ascent Rate Indicator)
– Control Of Displays
– No Decompression Dive Mode. No Deco Dive Mode Safety Stop.
– Decompression Dive Mode
– Violation Modes. Conditional Violation Mode. Delayed Violation Mode. Immediate Violation and Violation Gauge Mode.
– High PO2
– High Oxygen Accumulation
POST DIVE MODES
– Post Dive Surface Mode
– Transition Period
– After The Transition Period (The First 2 Hours). Time to Fly / Desaturate. Pre Dive Planning Sequence. Log Mode.
– After The First 2 Hours
– Wet Contacts
– Reset Feature
GENERAL
– Care And Cleaning
– Inspections And Service
– Module Removal From Boot
– Battery Replacement
– Returning the Module to Boot
– Altitude Compensation
– Specifications
– Notes
– Service Record
POWER:
– Battery: 1 – 3 vdc, type CR2450 Lithium battery
– Shelf life: Up to 5 years
– Replacement: User replaceable (annual recommended)
– Life expectancy: 100 dive hours (if 1 – 1 hour dive per dive day) to over 300 dive hours (if 3 – 1 hour dives per dive day)
