BigBlue CellPowa 600 Portable Power Station User Manual

Description

This PDF user manual is for the BigBlue CellPowa 600 power station.

About the Item

BigBlue CellPowa 600 Portable Power Station 600W (1,200W surge) Pure Sine Wave 537.6Wh LiFePO4 3,500+ cycles (at 80% capacity charged)

Meet the BigBlue CellPowa 600, an ultra-compact and lightweight lithium iron phosphate (LiFePO4) portable power station – Manic Miniature. It is loaded with 537.6 watt-hours of capacity and rated at 600 watts output while maintaining the cleaner pure sine wave profile. The BigBlue CellPowa 600 portable power station offers safe, efficient, and reliable power in emergencies or when traveling. Modeled after the BigBlue portable power station series, the CellPowa 600 is set to deliver a new benchmark in power supply with astounding performance without breaking the bank.

Please read this manual to obtain the best performance from your BigBlue CellPowa 600.
Read all the instructions. Keep these instructions. Heed all warnings. Follow all instructions.

(PDF) USER MANUAL (ENGLISH) (日本語)

SUMMARY OF CONTENTS

IMPORTANT SAFETY INSTRUCTION
– Product Use
– Product Cleaning
– Product Charging
– Product Storage
– Product Disposal
– Product Maintenance
– Warranty Conditions. What warranty excludes.

INTRODUCTION OF BIGBLUE CELLPOWA 600

LIST AND DESCRIPTION OF OUTPUT PORTS

LIST AND DESCRIPTION OF INPUT PORTS

WHAT’S IN THE BOX

CONTROLS AND FUNCTIONS
– Product Indications
– Liquid-crystal Display Indications

SYSTEM OPERATIONS
– Power On / Off. How to power on / off the product.
– Power Saving Mode
– Recharging Mode – AC Input
– Recharging Mode – Solar Panel
– Recharging Mode – Car Cigarette Lighter Socket
– Charging Mode – AC Outputs. How to activate the AC output ports. How to reduce the power consumption when the unit is not in use.
– Charging Mode – DC Outputs (USB Type-A, USB Type-C)
– Charging Mode – DC Outputs (Car Cigarette Lighter Socket, DC 5521). How activate the car cigarette lighter socket and the DC 5521 ports.
– LED Flashlight. How to activate the LED flashlight. The LED flashlight offers tri-mode lighting; high task lighting, low moonlight, and SOS emergency mode. Press again the ‘LED Flashlight’ button to switch between the modes. How to switch off the LED flashlight.
– Utmost-B Charging Mode (boost-up mode). How to activate the ‘Utmost-B Charging’ mode.
– Pass-through Charging
– 10ms Uninterruptible Power Supply

SYSTEM SPECIFICATIONS
– General Information
– Output Ports
– Input Ports
– Battery Information
– Environmental Operating Temperature

FREQUENTLY ASKED QUESTIONS
1. WHAT TYPE OF BATTERY DOES THE CELLPOWA 600 PORTABLE POWERSTATION USE?
As ever, BigBlue has adapted the exalted electrical vehicle grade lithium iron phosphate (LiFePO4) battery. Compared to the most market-found ternary portable power stations, which use lithium-ion or lead acid; the CellPowa 600’s LiFePO4 portable power station is safer as better stability at high temperatures and has a longer life span (at least 4 to 5 times longer), complementing to around 3,500+ cycles.

2. WHAT APPLIANCES CAN BE CHARGED VIA THE CELLPOWA 600 ‘S AC OUTPUT PORT?
With a large 537 watt-hours capacity, extra AC wattage up to a total of 600W, in addition to 2 x USB PD Type-C ports rated at 160 watts output in total;
CellPowa 600 is the centerpiece designed for the class-leading power station for home backup, off-grid life, and professional work. Plus, the extra feature via its ‘Utmost-B Charging’ (boost-up mode), with the capability to boost up the output to 800 watts when connected to heavy-duty devices.

3. HOW DO I KNOW THE CELLPOWA 600 IS RECHARGED?
When the CellPowa 600 is being recharged, the blue circular progress bar will rotate.

4. CAN I USE THIRD-PARTY SOLAR PANELS TO RECHARGE THIS PRODUCT?
Yes. You can connect via provided MC4-to-DC 5525 cable to any solar panel, with a range of 12-30V / 5A, with maximum 120W input to recharge the CellPowa 600 power station. Do not mix using different types of solar panels.

5. CAN I RECHARGE THE CELLPOWA 600 WHILE SUPPLYING THE POWER AT THE SAME TIME?
The CellPowa 600 can recharge itself and supply power to the connected devices at the same time.

6. WHY SHOULD OVERCHARGE AND OVER-DISCHARGE BE AVOIDED?
Overcharging and over-discharge will shorten the battery’s life span. It is recommended to keep the battery charged between 20% and 80%.

7. WHAT IS THE CASING OF THE CELLPOWA 600 MADE OF? IS IT ENVIRONMENTALLY FRIENDLY?
The casing of CellPowa 600 is made of premium and durable flame-retardant polycarbonate ABS alloy (PC-ABS with UL94 V-0 rated). It has improved strength and thermal resistance. The material is environmentally friendly.

8. HOW DOES THE UNINTERRUPTIBLE POWER SUPPLY (UPS) OPERATE?
The CellPowa 600 portable power station supports pure sine wave Uninterruptible Power Supply (UPS) to replenish and maintain the power supply (switches from the power grid to battery supply) in a split of 10 milliseconds when the incoming power from the power grid is interrupted.
NOTE: Do enable the AC button for this UPS feature.

TROUBLESHOOTING
Error Code – Error Description
00 – Inverter – Over Voltage
01 – Inverter – Under Voltage
02 – Inverter – Over Current
04 – Inverter – Short Circuit
05 – Inverter – Overload Warning
06 – Inverter – Overload Protection (unit will be locked)
07 – Inverter – Faulty Fuse
08 – Inverter – Faulty Relay
16 – Battery – Over Voltage
17 – Battery – Over Voltage
18 – Battery – Under Voltage
19 – Battery – Under Voltage
20 – Battery – Over Current
24 – Battery – Faulty Fuse
25 – Battery – Faulty Relay
40 – Bypass – Over Voltage
41 – Bypass – Under Voltage
42 – Bypass – Over Frequency
43 – Bypass – Under Frequency
44 – Bypass – Short Circuit
45 – Bypass – Overload Warning
46 – Bypass – Overload Protection (unit will be locked)
47 – Bypass – Fuse Faulty
48 – Bypass – Relay Faulty
88 – Radiator – Over Temperature Warning
89 – Radiator – Over Temperature Protection (unit will be locked)
90 – Radiator – Low-Temperature Warning
91 – Radiator – Low-Temperature Protection (unit will be locked)
92 – The thermostatic radiator valve is not connected
93 – Internal – Over Temperature Warning
94 – Internal – Over Temperature Protection (unit will be locked)
95 – Incorrect Voltage
99 – Internal Faulty
