Daewoo GDA 7500DFE Dual Fuel Petrol-Gas Generator Instruction Manual

Description

This PDF user manual is for the Daewoo GDA 7500DFE dual fuel generator.

About the Item

Daewoo GDA 7500DFE Dual Fuel Petrol-Gas Generator 6kW (6.5kW max) 230 V (with electric starter)

The DAEWOO generator is a device for generating electric current. Generators are great for powering small houses, construction sites, as well as solving problems for small businesses and tourism.

Dual Fuel fuel system: The Dual Fuel fuel system makes it possible to use liquefied petroleum gas (propane-butane) as fuel for the generator. The gas oxidizes almost completely in combustion chamber that leads to a lesser emissions and a 1.5 increase of engine life. Using Duel Fuel generators leads to 50-65% lesser operating costs in comparison to gasoline generators.
Electric starter: A built-in electric starter and battery make it easier for operators to operate the generator by turning on of the ignition key without pulling the starter. The key makes starting easy and comfortable for users.
ATS or the automatic transfer switch: The generator is equipped with ATS input. The alternator management system can be connected to the generator during a power outage.

FEATURES
– The Daewoo engine for professionals
– Increased fuel tank capacity up to 30 liters
– Quick start
– The voltmeter
– The AVR (Automatic Voltage Regulator)
– The over-current smart protection
– Low-oil level shutdown
– Low noise level
– The sturdy frame
– The copper alternator
– The transportation kit (option)

TECHNICAL DATA
– Maximum power: 6.5 kW
– Rated power: 6.0 kW
– Voltage: 230 V
– Voltage regulator: AVR
– Power Factor: 1 Cosine phi
– Sockets: 1x16A, 1x32A
– ATS Connector: yes
– Run time 50% load: 17 h
– Sound power level: 96 dB(A)
– Displacement: 420 cu.cm
– Engine power: 15 HP
– Engine model: 420
– Engine type: 4-stroke
– Engine manufacturer: DAEWOO
– Fuel type: Petrol-Gas
– Fuel tank volume: 30 l
– Oil volume: 1,1 l
– Starter battery: yes
– Starting system: manual-electro
– Transportation kit: no
– Dimensions (L/W/H): 680x520x540 mm
– Weight: 84.8 kg

Please note that before using the equipment, you must carefully read the manual.
If you encounter problems, please use the helpful information at the end of the manual.

(PDF) INSTRUCTION MANUAL (ENGLISH) (DEUTSCH) (FRANÇAIS) (POLSKI) (УКРАЇНСЬКА) (LATVIEŠU VALODA) (LIETUVIŲ KALBA) (EESTI KEEL) (SUOMI) (ČEŠTINA)

SUMMARY OF CONTENTS

PRODUCT DESCRIPTION

DELIVERY SET

GENERAL VIEW AND COMPONENTS
– Control Panel

SPECIFICATIONS

SAFETY INFORMATION

DESCRIPTION OF SYMBOLS

PREPARATION FOR WORK
– Operating Conditions
– Checking Oil Level
– Checking Fuel Level
– Preparing The Air Filter

OPERATION OF THE GENERATOR
– Starting The Engine
– Engine Stop
– Generator Emergency Switch
– Emergency Switch Of 16A Socket
– Using The Generator In ATS Mode
– ATS Operation In Auto Mode
– FEATURES OF GAS GENERATOR OPERATION
– STARTING AND STOPPING THE ENGINE

MAINTENANCE
– Changing / Filling Oil In The Engine
– Recommended Oils
– Recommended Oils, Depending On Ambient Temperature
– Air Filter Maintenance
– Spark Plug Maintenance
– Generator Storage
– Transportation
– Recommended Maintenance Schedule

TROUBLESHOOTING
– Engine doesn’t start
– Difficulty starting or reduced engine power
– The engine overheats
– Engine starts but no output voltage
– Generator runs but does not support connected electrical devices

DEVICE DISPOSAL

DECLARATION OF CONFORMITY

WARRANTY

Why download the Manual?

This user manual provides all the information from Daewoo Power Products about the GDA 7500DFE petrol generator, as detailed in the table of contents. Reading it completely will address most questions you might have. You can download and save it for offline use, including viewing it on your device or printing it for your convenience if you prefer a paper version.
