Duraflame DFS-950-7 Electric Stove (with Heater) Instruction Manual
Download PDF user manual for Twin-Star International / Duraflame DFS-950-7 Electric Fireplace Stove with Heater, 1500 Watts (EN) 2 pages 2013 zip
Description
This PDF instruction manual is for the Duraflame DFS-950-7 Electric Stove with Heater.
About the Item
Duraflame DFS-950-7 Electric Fireplace Stove with Heater, 1500 Watts
Read all instructions before using this appliance. Save these instructions.
DOCUMENT(S) AVAILABLE
(PDF) INSTRUCTION MANUAL
Available Languages
ENGLISH (EN)
SUMMARY OF CONTENTS
ASSEMBLY INSTRUCTIONS
– Mounting The Legs
OPERATING INSTRUCTIONS
POWER:
– The Power button supplies power to all of the functions of the stove.
HEATER:
– To turn on the heater press the HEATER button on the remote or control panel.
– The first setting is 750W, press the HEATER button again to change to 1500W.
– When using the remote, 1 beep is 750W, 2 beeps is 1500W.
REPLACING THE LIGHT BULB
PRODUCT SPECIFICATIONS
– VOLTAGE: 120 VAC, 60 Hz
– AMPS: 12.5 Amps
– WATTS (Max.): 1500 Watts
Note: When first running the heater there can be an odor. This is normal, the heater has a surface coating on the internal parts, for the first several hours of operation the coating reacts with the internal parts to permanently protect them. The odor is safe; if you are sensitive to the odor it is recommended to run the heater in a well-ventilated area until the odor dissipates.
IMPORTANT INSTRUCTIONS
When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electrical shock, and injury to persons.
BATTERY REPLACEMENT
WARRANTY
– If warranty service is needed
TROUBLESHOOTING GUIDE
1. No power
– Power cord was not plugged into the outlet.
– Circuit board failure
2. Stove does not turn on manually.
– No incoming power from the electrical wall socket or buttons.
– Improper operation.
– Control panel circuit board failure
3.Stove does not turn on with remote.
– Improper operation
– Remote control not working
4. Flames are not moving
– Defective Flame Generator Drive Motor
– Flame Generator/Spinner detached from the Flame Generator Drive Motor
5. Flames are not visible
– Burnt out light bulb.
6. Flames are not bright
– Normal operation
7. Heater is not turning on
– Defective Main PCBA
– Defective heater blower motor
8. Heater is not turning on and beeps many times when pressing the heater button
– The HEATER function is locked.
9. Not producing enough heat
– power strip/surge protector/ extension cord being used
– Location of unit
10. Unit blows cool or cold air
– Defective heater blower assembly.
11. Excessive noise with heater on
– Dirty heater blower motor
– Defective heater blower motor
12. Noise with flames on and heater off
– Defective flame generator drive motor.
– Dented back panel
– Warped Flame Generator/Spinner shaft
13. Power cord gets warm
– Normal operation
14. Is it safe to place unit on carpet?
– It is safe to place the unit on carpet; only operate with the legs installed and make sure to keep flammable items at least 3 feet (0.9 M) away from the front and sides of the unit.
15. How many square feet will my unit warm up?
– Provides supplemental heat up to 400 square feet.
