KAB RC-021 / TR-033-7 Digital Timer (with Remote Control) Operating Instructions
Download PDF user manual for KAB RC-021 / TR-033-7 Outdoor Digital Timer (3-outlet Outdoor Countdown Power Center) with Remote Control (EN) zip
Description
This PDF instruction manual is for the KAB RC-021 / TR-033-7 Digital Timer with Remote Control.
About the Item
KAB RC-021 / TR-033-7 Outdoor Digital Timer (3-outlet Outdoor Countdown Power Center) with Remote Control
Receiver Model #RC-021
Transmitter Model #TR-033-7
FEATURES
– Control electrical outlet up to a distance of 80 feet.
– Has three grounded receptacles.
– Weather resistant housing protects connected lighting.
– Countdown function automatically turns power off 2,4,6,8 hours later.
Read all instructions before use. Save these instructions.
DOCUMENT(S) AVAILABLE
(PDF) OPERATING INSTRUCTIONS
Available Languages
ENGLISH (EN)
SUMMARY OF CONTENTS
BUTTON LAYOUT
1. Sensor
2. Operating Mode
3. Select button
4. Outlets
5. Transmitter
CAUTIONS
INSTALLATION
OPERATION
– Receiver & Transmitter operation modes.
Note for Transmitter: Control electrical outlet up to a distance of 100 feet.
Note: In the sensor mode, any external light sources will not interfere with the photocell function, unless the external light source is on for more than 15 minutes. In that case, the timer will shut off until darkness is restored. The improvement avoids the flickering.
HELPFUL TIPS
– Once programming activates at dusk in the 2hr, 4hr, 6hr, or 8hr mode, the program cycle will complete before the timer resets. Headlights, porch lights, street lamps and other external lighting sources will not interfere with the active timer program.
– The timer has daily repeat after setting, in case of power failure, it will stop operating when the power goes out. Once power is restored, reset the desired operating mode as the operating instructions.
– When set to “ON”, the timer will provide continual power to attached devices until the timer is switched to “OFF”, or to any of the other operating modes.
BATTERY HANDLING AND USAGE
BATTERY REPLACEMENT (CR2032 battery)
SPECIFICATIONS:
– 14/3 AWG SJTW vinyl cord
RATINGS:
– 125Vac, 60Hz, 15 A General Purpose, 15 A Resistive, 1000 W Tungsten, 500 VA Electronic Ballast, 1/2 HP, 120Vac, 60Hz, 8.3A Ballast.
