LM111 TI Differential Comparator Data Sheet
Download PDF datasheet for Texas Instruments LM111 Single High-Speed Voltage Comparator (EN) 41 pages SLCS007K 2017 zip
Description
This PDF datasheet is for the TI LM111 voltage comparator.
About the Item
Texas Instruments LM111 Single High-Speed Voltage Comparator
LM111FK, LM111JG
Single High-Speed Voltage Comparator
This devices is designed to operate from a wide range of powersupply voltages, including +/-15 V supplies for operational amplifiers and 5 V supplies for logic systems.
The output levels are compatible with most TTL and MOS circuits. These comparators are capable of driving lamps or relays and switching voltages up to 50 V at 50 mA.
All inputs and outputs can be isolated from system ground.
(PDF) DATASHEET (ENGLISH)
SUMMARY OF CONTENTS
– Features
– Applications
– Description
– Revision History
– Pin Configuration and Functions
– Specifications: Absolute Maximum Ratings, ESD Ratings, Recommended Operating Conditions, Thermal Information (8-Pin Packages), Thermal Information (20-Pin Package), Electrical Characteristics, Switching Characteristics, Typical Characteristics
– Parameter Measurement Information
– Detailed Description: Overview, Functional Block Diagram, Feature Description, Device Functional Modes
– Application and Implementation: Application Information, Typical Application, System Examples
– Power Supply Recommendations
– Layout: Layout Guidelines, Layout Example
– Device and Documentation Support: Related Links, Receiving Notification of Documentation Updates, Community Resources, Trademarks, Electrostatic Discharge Caution, Glossary
– Mechanical, Packaging, and Orderable Information
